Product Description
Warn | VR EVO Standard Duty 12V Electrical Recovery Winch | Universal | 8,000lb, 10,000lb and 12,000lb pull capacities, Optional Steel Cable or Synthetic Rope recovery lines, Mounting Bolt Pattern 10.0" x 4.5"
Standard-duty winches with a steel or synthetic cable and pulling capacities of 8,000, 10,000, and 12,000 pounds. These are designed and engineered in the USA by WARN engineers. With its fast line-speed and lower amp draw, the VR EVO winches are the hardest-working standard-duty winches ever made by Warn, with tactical styling that looks great up front and at a price that won’t pull you out of your budget.
With the lowest amp draw and fastest line speed under load, the VR EVO series of winches are the hardest-working, standard-duty winches we’ve ever offered. Ideal weight capacity and line speed for 1/2-ton pickups, Jeeps, and larger SUVs. Each Winch features IP68-rated waterproof construction for performance in all conditions, a 2-in-1 wired and wireless remote, and our legendary reliability—standard. Plus, they’re covered by our industry-leading limited lifetime warranty.
VR EVO Recovery Winch Features:
- Recovery capacities of 8,000, 10,000 and 12,000 pounds
- Available with steel cables or synthetic rope options
- Mounting Bolt Pattern 10.0" x 4.5" (254mm x 114.3mm)
- A powerful series-wound motor and planetary gear train deliver faster line speed under load, with lower amp draw
- IP68-rated waterproof winch construction keeps the elements out
- High-performance Albright contactor delivers maximum reliability
- Control packs can be relocated for low-profile installations
- Durable, one-piece cast-aluminum tie-plate for added strength and durability
- 2-in-1 wired and wireless remote
- Limited lifetime warranty for mechanical parts and 7 years on the electrical
| VR EVO 8, VR EVO 8-S SPECS/PART NUMBERS |
| Part Numbers: PN 103250 (VR EVO 8), 103251 (VR EVO 8-S) |
| Rated Line Pull: 8,000 lbs (3629 kgs) |
| Motor: 12V DC, Series Wound™ |
| Electrical Controls: Albright Contactor |
| Remote Control: Wired remote with 11.5' (3.5m) Lead |
| Geartrain: 3-Stage Planetary |
| Gear Ratio: 218:1 |
| Clutch (freespooling): Rotating Ring Gear Clutch |
| Brake: Spring Brake |
| Drum Diameter/Length: 2.5"/9.0" (6.73cm/23cm) |
| Weight: Shipping Steel - 83.53 lbs (37.89 kgs), Shipping Synthetic - 72.40 lbs (32.84 kgs) |
| Rope: Steel - 5/16" x 90' (8mm x 27.4m), Synthetic - 3/8" x 90' (9.5mm x 27.4m) |
| Fairlead: Steel - Roller, Synthetic - Die Cast Hawse |
| Recommended Battery: 650 CCA min. for winching |
| Battery Leads: .098" x 6.5' (25mm x 2m) |
| Finish: Powder coat finish over primer undercoat |
| Warranty: Limited Lifetime |
| VR EVO 8, VR EVO 8-S: 12V DC Performance Specs (based on first layer of drum) | |||
| Line Pull Lbs (Kgs) |
Line Speed Ft/min (M/min) |
Motor Current |
Pull by layer layer/Lbs (Kgs) |
| 0 | 24.8 (7.6) | 57 amps | 1/8000 (3630) |
| 2000 (910) | 13.1 (4.0) | 122 amps | 2/6716 (3046) |
| 4000 (1810) | 9.6 (2.9) | 183 amps | 3/5788 (2625) |
| 6000 (2720) | 7.6 (2.3) | 242 amps | 4/5085 (2306) |
| 8000 (3630) | 6.0 (1.8) | 298 amps | |
| VR EVO 10, VR EVO 10-S SPECS/PART NUMBERS |
| Part Numbers: PN 103252 (VR EVO 10), 103253 (VR EVO 10-S) |
| Rated Line Pull: 10,000 lbs (4536 kgs) |
| Motor: 12V DC, Series Wound™ |
| Electrical Controls: Albright Contactor |
| Remote Control: Wired Remote with 11.5' (3.5m) Lead |
| Geartrain: 3-Stage Planetary |
| Gear Ratio: 218:1 |
| Clutch (freespooling): Rotating Ring Gear Clutch |
| Brake: Spring Brake |
| Drum Diameter/Length: 2.5"/9.0" (6.73cm/23cm) |
| Weight: Shipping Steel - 91.93 lbs (41.7 kgs), Shipping Synthetic - 72.40 lbs (32.84 kgs) |
| Rope: Steel - .354" x 90' (9mm x 27.4m), Synthetic - 3/8" x 90' (9.5mm x 27.4m) |
| Fairlead: Steel - Roller, Synthetic - Die Cast Hawse |
| Recommended Battery: 650 CCA min. for winching |
| Battery Leads: .098" x 6.5' (25mm x 2m) |
| Finish: Powder coat finish over primer undercoat |
| Warranty: Limited Lifetime |
| VR EVO 10, VR EVO 10-S: 12V DC Performance Specs (based on first layer of drum) | |||
| Line Pull Lbs (Kgs) |
Line Speed Ft/min (M/min) |
Motor Current |
Pull by layer layer/Lbs (Kgs) |
| 0 | 27.1 (8.3) | 58 amps | 1/10000 (4536) |
| 2000 (910) | 13.9 (4.2) | 125 amps | 2/8226 (3731) |
| 4000 (1810) | 9.9 (3.0) | 185 amps | 3/6987 (3169) |
| 6000 (2720) | 8.2 (2.5) | 244 amps | 4/6072 (2754) |
| 8000 (3630) | 6.5 (2.0) | 303 amps | 5/5370 (2436) |
| 10000 (4536) | 5.2 (1.6) | 358 amps | |
| VR EVO 12, VR EVO 12-S SPECS/PART NUMBERS |
| Part Numbers: PN 103254 (VR EVO 12), 103255 (VR EVO 12-S) |
| Rated Line Pull: 12000 lbs (5443 kgs) |
| Motor: 12V DC, Series Wound™ |
| Electrical Controls: Albright Contactor |
| Remote Control: Wired Remote 11.5' (3.5m) Lead |
| Geartrain: 3-Stage Planetary |
| Gear Ratio: 234:1 |
| Clutch (freespooling): Rotating Ring Gear Clutch |
| Brake: Spring Brake |
| Drum Diameter/Length: 2.5"/9.0" (6.73cm/23cm) |
| Weight: Shipping Steel - 90.81 lbs (41.19 kgs), Shipping Synthetic - 72.27 lbs (32.84 kgs) |
| Rope: Steel - 3/8" x 85' (9.5mm x 25.9m), Synthetic - 3/8" x 90' (9.5mm x 27.4m) |
| Fairlead: Steel - Roller, Synthetic - Die Cast Hawse |
| Recommended Battery: 650 CCA min. for winching |
| Battery Leads: .098" x 6.5' (25mm x 2m) |
| Finish: Powder coat finish over primer undercoat |
| Warranty: Limited Lifetime |
| VR EVO 12, VR EVO 12-S: 12V DC Performance Specs (based on first layer of drum) | |||
| Line Pull Lbs (Kgs) |
Line Speed Ft/min (M/min) |
Motor Current |
Pull by layer layer/Lbs (Kgs) |
| 0 | 26.2 (8.0) | 55 amps | 1/12000 (5443) |
| 2000 (910) | 13.9 (4.2) | 120 amps | 2/9801 (4446) |
| 4000 (1810) | 9.5 (2.9) | 178 amps | 3/8283 (3757) |
| 6000 (2720) | 8.1 (2.5) | 234 amps | 4/7173 (3254) |
| 8000 (3630) | 6.8 (2.1) | 288 amps | 5/6324 (2869) |
| 10000 (4536) | 4.9 (1.5) | 337 amps | |
| 12000 (5440) | 4.0 (1.2) | 396 amps | |
